Beta is a versatile and compact range of high efficiency oil and gas fired mobile boiler houses with outputs from 100kW to 500kW. The range consists of three models B86 (100kW), B215 (250kW), and B413 (480kW). Each Beta is capable of providing high flow rates of hot water via an integral and highly flexible dual flow system suitable for heating and for sanitary use. |
BETA - High efficiency dual circuit packaged hot water boiler houses
|
|
Heat output |
Flow rates |
Head height |
Fuel use |
Electrical |
Noise level |
|
|
kw |
kCal |
litres/sec |
meters |
litres/hour |
V-ph-Hz |
dBA |
|
Beta 86 |
100 |
86,000 |
2.2 |
0.43 |
30 |
12.4 |
230-1-50 |
60 |
|
Beta 215 |
250 |
215,000 |
5.4 |
1.06 |
5.5 |
27.5 |
230-1-50 |
61 |
|
Beta 430 |
500 |
430,000 |
10.8 |
2.2 |
7 |
53.2 |
415-3-50 |
62 |
|
In common with the Alpha and Gamma Ranges the design features a fully welded rigid and immensely strong chassis with flush fitting insulated doors and removable panels to provide a very strong, robust, and extremely durable product. Again, like all our products each Beta is hand built to the highest standards, and is designed to withstand rigorous and prolonged use within the hire industry. Each Beta is fitted with four-way FLT pockets, lifting eyes, and is designed to be stacked when not in use.
Controls, outer panels, and external paint finishes can be detailed and specified by the customer with specifications to suit individual customer and application requirements.
Typical applications for Beta boiler houses include the following: construction sites, outdoor events and marquees, temporary kitchens and field hospitals, temporary toilet and shower units, decontamination units, temporary storage facilities, temporary LPHW heating coils within Air Handling Units, frost protection, warehousing, plant and building refurbishment, process heating, pest control, deep cleaning, and sterilisation, building drying and dehumidification, ship building and refitting, temporary heating within industrial and commercial units, under floor heating, greenhouses and agriculture, high pressure jet washing and process cleaning, in theatre military uses, and very many more… |
|
